Factors Affecting Reinforcement Corrosion in Concrete and Prevention Methods
Main Factors Leading to Steel Corrosion in Concrete
Carbonation of Concrete:
The reaction between atmospheric CO₂ and the calcium hydroxide in concrete reduces the pH around the reinforcing steel. When the pH drops below about 9, the protective passive layer on the steel surface is destroyed, making it susceptible to corrosion.
Chloride Ion Penetration:
Chloride ions, often from de-icing salts, sea water, or contaminated aggregates, penetrate the concrete and break down the passive film protecting the steel, leading to rapid local corrosion (pitting).
Poor Concrete Quality:
High water-to-cement ratio, inadequate compaction, insufficient curing, and use of porous or low-grade materials create a more permeable concrete, allowing aggressive agents to reach the steel more easily.
Cracking in Concrete:
Structural or shrinkage cracks serve as direct channels for water, oxygen, carbon dioxide, and harmful ions to reach the reinforcement.
Insufficient Concrete Cover:
Thin or poorly placed coverage permits environmental exposure and speeds up the ingress of aggressive substances to the steel bars.
Presence of Moisture and Oxygen:
Corrosion requires moisture and oxygen; high humidity or direct water exposure at the reinforcing bar’s depth accelerates the corrosion process.
Use of Contaminated Aggregates or Mixing Water:
Improper materials can introduce extra chlorides or other contaminants into the concrete mix.
Aggressive Environmental Conditions:
Marine environments, exposure to freeze-thaw cycles, and industrial atmospheres intensify the risk and rate of corrosion.
Solutions and Prevention Strategies
Use of High-Quality, Dense Concrete:
Lowering the water-to-cement ratio, adequate compaction, use of pozzolanic additives (like silica fume), and proper curing help achieve low-permeability concrete, which restricts the access of corrosive agents.
Increasing the Thickness of Concrete Cover:
Providing sufficient cover over the reinforcement bars (as specified in codes and standards) delays the penetration of moisture, CO₂, and chlorides.
Use of Corrosion Inhibitors:
Incorporation of chemical admixtures that inhibit chloride activity or corrosion reactions can significantly reduce steel corrosion risks.
Application of Surface Sealers or Coatings:
Applying waterproof, anti-carbonation, or silane-siloxane coatings on concrete surfaces minimizes the ingress of water and aggressive ions.
Use of Epoxy-Coated or Stainless Steel Reinforcement:
These bars are more resistant to corrosion, especially in harsh or marine environments.
Cathodic Protection:
Installation of sacrificial anodes or impressed current systems can counteract the electrochemical reactions causing corrosion.
Regular Inspection and Maintenance:
Timely repair of cracks, damaged cover, and surface deterioration prevents the initiation and progression of corrosion.
Proper Selection of Raw Materials:
Using clean, chloride-free aggregates and water for concrete mixing.
Design to Avoid Water Accumulation:
Adequate structural detailing and drainage prevent standing water and reduce wetting-drying cycles at the steel level.
Summary
The durability of reinforced concrete largely depends on the resistance of the rebar against corrosion. Combining quality concrete production, protective design, modern admixtures, barrier systems, and maintenance is essential for prolonging structural life and safety.
