DEZOFLOW P1
NON-SHRINK CEMENT BASED GROUTING MORTAR
DESCRIPTION
DEZOFLOW P1 is a non-shrink cementitious ready-mix grout with 60 MPa compressive strength. Due to the special combination of DEZOFLOW P1 it is useful for filling and grouting of base plates in steel structures and installation of heavy machineries with more than 100 mm grouting height.
ADVANTAGES
- Suitable for static loads
- No hardening crack
- Non-shrinkage
- Premixed grout requires only the addition of mixing water on site
- Excellent flowability
- High early strength and fast load bearing capacity
APPLICATION
- Filling and grouting of base plates in steel structures
- Installation of heavy machinery
- Installation of precast columns
- Anchor bolts
SURFACE PREPARATION
Surfaces should be clean sound and free from oil, grease, laitance and loose particles. Metal surfaces should also be clean and free of rust, oil, grease and contaminants.
The prepared areas should be flooded with water prior to the placement of DEZOFLOW P1 before the grout is placed. All free water should be released from the area to be grouted. There should be NO standing water present when the grout is placed.
MIXING
DEZOFLOW P1 should be mixed using a suitable mixer. For flowable consistency use a band drill and paddle with a speed of <400 rpm. For large works use a high shear vane grout mixer. The entire contents of the bag should be added to the pre-measured (2.625-3.250 liters) water while mixing.
DO NOT add more than the maximum water content.
APPLICATION
Ensure the substrate is prepared according to the manufactures recommendations. NO free water should be present in the area to be grouted. Ensure that there are sufficient air release holes for entrained air to escape.
Mortar should be continuously poured, from one side only, until the gap is completely filled. Maintain continuous head of grout when pouring.
CURING
It is necessary to cure exposed areas of grout with humidified method for at least 7 days.
PHYSICAL AND CHEMICAL PROPERTIES
Physical state: Powder
Color: Gray
Specific gravity of fresh mortar: 2.30±0.1 g/cm³
Chloride ion: No chloride content
STORAGE
Shelf life: 1 year in the original package
Storage condition: should be protected from direct sunlight and moisture. Keep bag in the temperature range between +10°C and +30°C.
Packing: 25 kg bag
HEALTH AND SAFETY
This product does not contain any substances hazardous to human health and the environment. However, it should not be swallowed and contact with skin and eyes. In case of contact with eyes, rinse immediately with plenty of water. DEZOFLOW P1 is not flammable.
For further information refer to the material safety data sheet. MSDS is available at CONCRETE CLINIC OF IRAN website.
TECHNICAL SERVICE
The CONCRETE CLINIC OF IRAN INTERNATIONAL GROUP Technical Department is available to assist you in the correct use of our products and its resources are at your disposal entirely without obligation.
All data presented in this technical datasheet are based on our last researches in CONCRETE CLINIC OF IRAN CONSTRUCTION CHEMICALS laboratories and are just as a guide for choosing appropriate material. Therefore, users should conduct a sufficient investigation to establish the suitability and conformity of any product for intended uses
