DEZOCRETE S-101
POWDER ACCELERATING ADMIXTURE / QUICK-SETTING FOR SHOTCRETE
DEZOCRETE S-101 is a non-alkaline accelerator of water-cement reaction. It can be used for dry mix shotcrete.
It is controlled based on: ASTM C1141, ASTM C1398 EN 934-5
ISIRI 2930-5, ISIRI 12601
APPLICATION
- Shotcrete for structural tunnel
- Particularly suitable for use of tunnel and channel lining
- Ground and rock slope sections stabilization
- Concreting in slope surfaces
- Underground structures lining
- Repairs Concrete Structures
ADVANTAGES
- Accelerates the hydration reaction
- Achieve to early compressive strength of concrete
- Increased adhesion
- Dry mix shotcrete for any thickness
- Reduction in the risks of rebound and dust
- Shotcrete at one layer up to 35 centimeters thickness
- High adhesion to concrete and stone sections
- Easy shotcrete applications
- No negative effects on reinforcement of concrete structures
- Cold weather concreting
- Prevents freezing of concrete and mortar
TECHNICAL NOTE
The following parameters effect on properties of DEZOCRETE S-101: 1- Cement content
2- Water-cement ratio
3- Ambient temperature
4- Temperature of DEZOCRETE S-101
5- Temperature of water and aggregate
6- thickness of shotcrete
7- Equipments and shotcrete method
DOSAGE
Depending on speed of concreting, the time required for shotcrete and Compressive strength, a dosage of between 2.0 and 7.0 percent by weight of cement is recommended. The optimum dosage of DEZOCRETE S-101 can be determined by trials in the site.
Note: For use with other range of dosage, contact ABADGARAN Technical Services Department. Please contact our engineering office in case of simultaneously use of more than one admixture.
Please contact our engineering office in case of simultaneously use of more than one admixture.
DIRECTION OF USE
DEZOCRETE S-101 should be used based on requirement of project. The following parameters effect on directions of use:
1- Mixing time and mixing method of DEZOCRETE S-101 with concrete mixture 2- Type of equipments
3- Nozzle of Shotcrete Machine
PHYSICAL AND CHEMICAL PROPERTIES
Physical state: Powder
Color: White
Specific gravity: 1.35+ 0.05 g/cm3
Chloride ion: Nil to EN 934
STORAGE
Shelf life: 1 year in the original package
Storage condition: should be protected from direct sunlight and moisture. Keep bag in the temperature range between +10°C and +30°C.
Packing: 20 kg bag
DEZOCRETE S-101 should be kept in the original package because it is reactive especially with moisture and dust. Recommended to be used immediately opened the bag.
HEALTH AND SAFETY
This product does not contain any substances hazardous to human health and the environment. However, it should not be swallowed and contact with skin and eyes. In case of contact with eyes, rinse immediately with plenty of water. DEZOCRETE S-101 is not flammable. For further information refer to the material safety data sheet. MSDS is available at CONCRETE CLINIC OF IRAN website.
TECHNICAL SERVICE
The CONCRETE CLINIC OF IRAN INTERNATIONAL GROUP Technical Department is available to assist you in the correct use of our products and its resources are at your disposal entirely without obligation.
