BETOGARG P 1
Crystallizing waterproofing coating of cement base
Description:
BETOGARG P 1 is single-component and based on cement compounds, with the ability to work in negative and positive pressure, in combination with water, it crystallizes during a chemical process and creates an impermeable coating on the surface and depth of old and new concrete structures. This product is available in gray and red colors.
Indications:
• To seal internal and external surfaces of all types of concrete structures under the effect of positive and negative hydrostatic pressure
• Potable water tanks
• Concrete tanks for holding urban and industrial wastes (concrete surface becomes resistant to corrosive substances)
• Reservoirs of water and sewage treatment plants
• Water and sewage transfer systems, marine structures and aquaculture ponds
• Building industrial cooling towers (cooling tower)
• Can be used in underground structures and on the ground
• Can be used on internal and external surfaces of structures
• Can be used in tunnels
Features and advantages:
• Resistant to positive and negative hydrostatic pressure
• Ability to block cracks and capillary tubes and reduce permeability
• Non-toxic and approved for contact with drinking water
• Impact and abrasion resistant
• Ease of implementation
• Very high penetration into concrete and formation of uniform texture with concrete
• Resistance to corrosion caused by municipal and industrial wastewater
• Resistant to sea water, chlorine ions and sulfates
Technical Specifications:
|
Content
Color
Mixing
Pot Life
Adhesion Strength
Capillary Water Absorption
Maturity Period
Application Temperature
Service Temperature
Application Tools
Drying Time
Mechanical Strength
Water Impermeability
Re-coat
Final Strength
|
Mineral fillers, Polymer Modified Additives and Special Cement
Grey
25 kg BETOGARG P 1: 7-8 L water
20 minutes
≥ 1.0 N/mm2
w<0.1 kg/m2.h0,5
3-5 minutes
+5°C to +30°C
-20°C to +80°C
Brush
1 day
7 days
3 to 5 hours
14 days
|
Mechanism of action:
After applying the BETOGARG P 1 product on the concrete surface, according to the law of capillary tubes and by osmotic mechanism, it penetrates into the concrete and reacts with free lime and existing moisture, and fills all the cracks and capillary tubes by making needle crystals and prevents it from reaching Water or any other type of fluid enters the concrete.
Consumption:
The consumption of BETOGARG P 1 product per square meter is about 1000 grams in one layer, at least two layers should be applied. It should be noted that the exact amount of consumption is affected by the quality and porosity of the concrete surface.
Method of Use:
First, we pour 7-8 liters of water into a suitable container and while stirring with an electric drill equipped with a suitable stirrer, we slowly add 25 kg of BETOGARG P 1 product to it in several stages. We continue to obtain a homogeneous mixture without lumps. The minimum time required for mixing is 3 minutes. (Prepare some product that you can use within 30 minutes)
After staining the surfaces under the work with BETOSIVE WP product, which is a restorative mortar with crystallizing properties, we moisten it with water and apply the first layer of BETOGARG P 1 crystallizing penetrant with a brush or spray so that all pores are in contact with the mixture. Apply, then apply the second layer in the direction perpendicular to the first layer.
After applying the second layer, the concrete surface should be cured by spraying water for 24 hours (three to four times a day). So From 5 to 7 days at most, the surfaces reach their maximum efficiency.
Packaging and storage:
BETOGARG P 1 product is available in 25 kg bags. The best time of use in the original packaging, away from moisture, freezing and direct sunlight, is one year.
