DEZOBOND P-1800
Epoxy Bonding Agent for Concrete
DESCRIPTION
DEZOBOND P-1800 is a solvent-free, two components concrete bonding agent, based on modified epoxy resins and especially designed hardeners. It provides a bond of far greater strength than the tensile strength of the concrete itself. Therefore, it is suitable for use wherever structural bonding of new to existing concrete is carried out. it meets all the requirements of the standard ASTM C882.
FIELD OF APPLICATION
- Bonding new to existing concrete and metals
- prevent water penetration and fix leakages
- injectable in concrete cracks
- improves bonding cementitious flooring to old concrete
ADVANTAGES
- Highly effective on damp and dry surfaces
- Excellent initial and final mechanical strength
SURFACE PREPARATION
All surfaces must be clean, free from frost standing water and all loosely adhering particles. Cement laitance must be removed and the surfaces to be treated must be mechanically roughened.
MIXING
Mix component A and B separately with a mixing paddle attached to a slow speed electric drill (max. 600 RPM). Add component B to component A and mix with the mixing paddle for 3 minutes until the material becomes smooth in consistency and color. Avoid entrapping air.
APPLICATION
After mixing apply directly to the prepared substrate by brush, roller or spray. On damp surfaces, ensure that it is well brushed in. Pour new concrete within specified open time, as long as material is still tacky.
DOSAGE
The optimum dosage of DEZOBOND P-1800 to meet specific requirements depends on porosity and roughness of the substrate. the dosage range for normal substrates is from 0.3 to 0.8 kg/m2.
APPLICATION CONDITIONS/LIMITATIONS
Substrate Temperature + 10 °C - + 30 °C
Ambient Temperature + 5 °C - + 25 °C
Material Temperature +15 °C - + 25 °C
Condition the material by also storing at this
temperature for 24 hours before use.
Dew Point Substrate temperature during application must
be at least 3°C above dew point to avoid
condensation
TECHNICAL PROPERTIES
Appearance Part A: white viscose liquid
Part B: black viscose liquid
Mixing Ratio (A:B) 3:1 (by weight)
Density (A+B) 1.4 ± 0.1 g/cm3
Compressive Strength 70 (N/mm2)
Flexural Strength 35 (N/mm2)
Tensile Strength 20 (N/mm2)
Drying Time
|
|
Temperature
|
|
|
Touch dry
|
|
|
Full cure
|
|
|
|
|
|
|
|
|
|
|
|
|
+15 °C
|
|
9 hrs
|
|
13 days
|
|
|
|
|
|
|
|
|
|
|
|
+25 °C
|
|
6 hrs
|
|
7 days
|
|
|
|
|
|
|
|
|
|
|
|
+40 °C
|
|
4 hrs
|
|
4 days
|
|
|
|
|
|
|
|
|
|
|
|
|
Pot life
|
|
Material temperature
|
|
|
+15 °C
|
|
|
+25 °C
|
|
|
+40 °C
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Pot life
|
|
45 min
|
|
30 min
|
|
20 min
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PACKAGING
4 kg set.
STORAGE & SHELFLIFE
The shelf life is 12 months if unopened, stored free from frost, moisture and direct sunlight.
HEALTH & SAFETY
This product is Flammable. Keep away from heat and open flame .Keep container closed .Use with adequate ventilation. Avoid prolonged and repeated contact with skin. If used in confined areas, observe the following precautions to prevent hazards of fire or explosion or damage to the health:
1-Circulate adequate fresh air continuously during application and drying. 2-Use fresh air masks and explosion proof equipment.
3- Prohibit all flames, sparks, welding and smoking. MSDS is available upon request.
TECHNICAL SERVICE
The CLINICBETON INTERNATIONAL GROUP Technical Department is available to assist you in the correct use of our products and its resources are at your disposal entirely without obligation.
All data presented in this technical datasheet are based on our last researches in CLINICBETON CONSTRUCTION CHEMICALS laboratories and are just as a guide for choosing appropriate material. Therefore users should conduct a sufficient investigation to establish the suitability and conformity of any product for intended uses.
