TILEBOND PA & PB
Ceramic glue and epoxy banding with high chemical resistance
Product description:
TILEBOND PA & PB, made on the basis of solvent-free epoxy, has three components (A, B, C) in the following two types:
• TILEBOND PA for installing ceramics on the floor and wall
• TILEBOND PB for bonding floor and wall ceramics
Application and uses:
Installing tiles and tiling on vertical and horizontal surfaces that are exposed to the attack of chemical and oil substances and physical pressures can be used.
• Dairy and food production factories
• Tanning, dyeing and electroplating workshops
• Industrial kitchens, hospitals and laboratories
• Sealing the inlet pipes of chemical tanks
• Installing stone and ceramics on the metal wall of the elevators
• Bonding and sealing concrete metal to metal and metal to stone materials
• Ceramic strapping of power plant and refineries facilities
Advantages of TILEBOND PA & PB:
• High adhesion to metal, cement and tile surfaces
• High chemical resistance against various compounds according to the relevant table
• Suitable for straps from 2 to 20 mm
• Can be cleaned with water before setting
• Available in different colors
• High mechanical resistances
• No shrinkage, shrinkage and cracking
Compliance with the standard:
• EN 13888 strapping requirements
• Requirements for tile adhesives EN 12004
Technical features:
|
material
|
Density
|
immersion time
|
Result
|
|
H2SO4
|
50%
|
7 days
|
Unchanged
|
|
HCL
|
30%
|
7 days
|
Unchanged
|
|
HNO3
|
10%
|
7 days
|
Unchanged
|
|
SEA WATER
|
-
|
7 days
|
Unchanged
|
|
NAOH
|
40%
|
7 days
|
Unchanged
|
|
H2SO4
|
10%
|
7 days
|
Unchanged
|
|
LACTIC ACID
|
10%
|
7 days
|
Unchanged
|
|
ACETIC ACID
|
20%
|
7 days
|
Unchanged
|
|
HNO3
|
50%
|
7 days
|
Unchanged
|
|
PETIOLCUM
|
-
|
7 days
|
Unchanged
|
Consumption:
TILEBOND PA for ceramic installation mortar 2 to 4 kg per square meter
Consumption rate for TILEBOND PB strapping mortar
• The width of the strapping is 3 mm and the depth is 5 mm, each meter length is 35 grams
• Strapping width 6 mm and depth 5 mm, each meter length 70 grams
• Strapping width 10 mm and depth 5 mm, each meter length 110 grams
TILEBOND PA & PB packaging:
• TILEBOND PA (A=1000 gr, B=500 gr, C=4250 gr)
• TILEBOND PB (A=1000 gr, B=500 gr, C=5500 gr)
• It should be noted that TILEBOND PA & PB have the same physical and chemical characteristics in parts A and B, and different in part C.
Technical Specifications:
|
The specific weight of the composition is kg/liter
|
1.9-1.7
|
|
Slippage (EN 1308)
|
0.5>
|
|
7-day compressive strength based on EN 1288-3 standard
|
800<
|
|
7-day bending strength based on EN 12808-3 standard
|
300<
|
|
Tensile strength
|
150<
|
|
Shear adhesion strength based on EN 12003 standard
|
50<
|
|
Duration of use at a temperature of 20 degrees Celsius
|
30 minutes
|
|
Open time at 20 degrees Celsius
|
More than 20 minutes
|
|
Concentration
|
0.1% >
|
Preparation:
• The work surface should be smoothed and prepared for ceramic implementation.
• The surface of the ceramic installation site has adequate resistance so that the surface will not be damaged by carrying heavy equipment after installing the ceramic.
• It should be noted that the thickness of TILEBOND PA & PB mortar for ceramic installation is maximum 4 mm. Therefore, it is necessary to remove the concrete pockmarks before installation and repair the surface with repair mortars according to the technical specifications of the relevant products and install ceramics after one week.
• Dust and any contamination should be removed from the surface.
• Remove from the surface in places where the contamination has been absorbed deep into the concrete.
• It is recommended to apply the coating between 10 and 35 degrees Celsius.
• The surface under the work should be dry and free of moisture during execution.
• In order to better bond the ceramic installation mortar to the surface under the concrete work, a special primer is used with a brush.
How to make ceramic installation mortar:
• After mixing the materials experimentally, calculate the time taken according to the ambient temperature and plan the next mixture.
• In the first step, parts A and B are mixed according to the given proportions and then powder C is mixed according to the given proportions to obtain a homogeneous mixture.
• Mortar prepared with a toothed trowel is placed on the execution surface, then ceramic is installed.
How to make anti-acid bonding mortar:
• To make the jointing mortar, first mix parts B and A, then add the powder of part C to it to prepare a stiff, non-sticky mortar, then apply it with a jointing trowel.
• Stringing is done after 3 days of ceramic installation. If the mortar for ceramic installation is made of mortar, it can be used for up to 6 months in the condition of preservation and storage at a temperature of 5 to 35 degrees and in a dry environment in the original packaging.
Technical services:
The technical department of Rayehe Beton Sabz Company (technical and specialized concrete clinic of Iran) is ready to cooperate and provide services for the correct use of its materials.
